Vimec AR:IA Commercial Cabin Lift
The Vimec AR:IA is a fully enclosed commercial cabin lift for safe, efficient passenger transport in public buildings. Its oil-free, machine-room-less (MRL) system saves space and reduces energy use, while advanced safety features ensure compliance. With varied cabin sizes, door options, and finishes, it adapts to both new builds and retrofit projects.
Lift Enquiry
Product Pages Enquiry Form
material options.
Why Commercial Buildings Choose the AR:IA
Multiple cabin sizes, entrance layouts, and door types allow integration into a variety of environments, while the robust design supports regular daily use. With advanced safety systems and low energy consumption, the Vimec AR:IA Commercial Cabin Lift provides reliable, compliant access in settings where accessibility is essential.
Commercial Sectors We Cover
The Vimec AR:IA Commercial Cabin Lift is suitable for a wide range of public and commercial environments.
With multiple cabin sizes, door configurations, and finish options, the lift can be built to match passenger volumes, interior styles, and accessibility requirements in almost any setting.
Performance & Safety
Drive System |
Oil-free, MRL design, with no separate machine room required. |
Motor Control |
Belt drive with inverter for smooth acceleration and deceleration. |
Load Capacity |
4–5 persons or a wheelchair user and an attendant. |
Compliance |
Meets European Machinery Directive 2006/42/EC for commercial installations. |
Safety Features |
Full-height light curtain barriers, overload detection, and door interlocks. |
Emergency Systems |
Battery-powered emergency lowering, fire alarm auto homing, and auto-dialler with 4G UK GSM and battery backup power supply. |
Adaptable Finishes for Brand Image & Usage
Wall panels, flooring, and ceiling finishes can be replaced or upgraded at any stage without altering the main lift system. This allows the lift to be adapted for refurbishments, rebranding, or changes in building use. A wide choice of materials and colours is available, enabling alignment with corporate identity or heritage interiors.
Design & Comfort
Cabin Sizes |
Range of standard and bespoke dimensions to suit building layout. |
Door Types |
Automatic telescopic doors in steel, glass, or additional finishes. |
Wall Finishes |
Wood effect, steel, skinplate, and textured panels; options to match corporate or heritage interiors. |
Flooring Options |
Rubber, marmoleum, and other finishes in a variety of colours. |
Glazing Options |
Full or half glazing; transparent or grey-tinted safety glass. |
Mirrors Options |
Full, half, or vertical mirror panels available. |
Lighting |
Integrated LED lighting with configuration options. |
Handrail |
Optional matt black aluminium handrail. |
Upgrade Capability |
Wall, floor, and ceiling finishes can be replaced without changing the lift system. |
Greener Mobility for Commercial Environments
The Vimec AR:IA Commercial Cabin Lift is designed for long-term use and adaptability, helping reduce lifecycle costs and environmental impact.
Its oil-free, MRL drive system lowers energy consumption and removes the need for hydraulic fluids. Cabin walls, flooring, and ceiling finishes can be replaced without altering the main lift system, allowing updates to match refurbishments or branding. Sustainable wall panel options further support environmental commitments.
Technical Specifications
Rated Speed |
Up to 0.15 m/s |
Load Capacity |
400 kg standard (4–5 persons) / 450 kg heavy-load version (5–6 persons) |
Travel Height |
Up to 14.6 m |
Maximum Stops |
6 |
Pitb Depth |
120 mm (vinyl floor) / 140 mm (other flooring) |
Minimum Headroom |
2,600 mm (telescopic doors) |
Door Height |
2,000 mm |
Motor Size |
1.5 kW standard / 2.2 kW heavy-load version |
Power Supply |
Single-phase 25A / heavy-load version available |
Standard Cabin Height |
2,000 mm |
Door Configuration |
Maximum 2 doors per floor |
Why Choose Gartec?
We have over 30 years of experience delivering lift solutions for commercial and public buildings across the UK. Our team understands the compliance requirements for accessibility in high-traffic environments and manages every stage of the project in-house, from specification to installation and maintenance, with nationwide coverage.
Reliable, Compliant Access for Commercial Buildings
The Vimec AR:IA Commercial Cabin Lift delivers safe, compliant, and adaptable passenger transport for a variety of commercial settings. Book a free site survey or consultation today to see how the AR:IA can be constructed to your building’s needs.
BOOK A FREE SURVEY
Speak To Our Team Today
FAQs
How disruptive is installation? |
A standard two-stop AR:IA can often be installed in under a week. The shallow pit depth and minimal headroom reduce the need for extensive structural work, making it suitable for retrofit projects with minimal disruption to day-to-day operations. |
How much does the AR:IA Commercial Cabin Lift cost? |
Final costs depend on cabin size, finishes, number of stops, and installation requirements. A detailed quotation is provided following a site survey and specification review. For more information, please contact sales@gartec.com |
Does the AR:IA meet commercial compliance standards? |
Yes. The AR:IA meets the European Machinery Directive 2006/42/EC and Electromagnetic Compatibility Directive (2014/30/EU), and includes safety features such as full-height light curtain barriers, overload protection, emergency lowering, fire alarm auto homing, and auto-dialler with 4G UK GSM and battery backup power supply. |
What maintenance is required? |
The lift is designed for easy servicing from inside the cabin, reducing downtime. We offer ongoing maintenance packages to ensure continued safe and efficient operation in high-traffic settings. |
What is the maximum capacity? |
The AR:IA is available with a standard 400 kg load capacity, or a 450 kg heavy-load version, suitable for 4–5 passengers or a wheelchair user with their attendant. |
