Aritco PublicLift Access
The Aritco PublicLift Access is our most versatile commercial platform lift, designed for reliable accessibility in offices, schools, retail, healthcare, and public buildings. Part M and Equality Act compliant, it installs in just a few days with minimal building work, providing long-term, inclusive access in any environment.
Lift Enquiry
Product Pages Enquiry Form
Why Businesses Choose the Aritco PublicLift Access
Designed to make accessibility effortless, the Aritco PublicLift Access suits every kind of public and commercial space, from schools and clinics to offices, shops, and leisure venues. Its modular structure adapts to one, two, or three entry sides and installs using a shallow 50 mm pit or surface ramp.
At its core, Aritco’s proven screw-and-nut drive system delivers smooth, energy-efficient travel that meets both Part M and Equality Act standards. The result is inclusive movement for all users, including wheelchair and mobility aid passengers.
Backed by UK engineering expertise and nationwide service support, it’s a trusted choice for projects that demand performance, reliability, and compliance.
Platform Sizes & Load Ratings
900 × 1040 mm (800 mm doors) |
250 kg capacity Not Part M compliant Structural opening: 1305 × 1190 mm
|
900 × 1280 mm (800 mm doors) |
410 kg capacity Not Part M compliant Structural opening: 1305 × 1430 mm |
900 × 1480 mm (800 mm doors) |
410 / 500 kg capacity (3-phase required for 500 kg) Through or single entry Structural opening: 1305 × 1630 mm |
1000 × 1280 mm |
410 kg capacity Not Part M compliant Structural opening: 1405 × 1430 mm |
1000 × 1480 mm |
410 / 500 kg capacity (3-phase required for 500 kg) Through or single entry Structural opening: 1405 × 1630 mm |
1000 × 1980 mm |
500 kg capacity (3-phase required) Through or single entry Structural opening: 1405 × 2130 mm |
1100 × 1480 mm |
410 / 500 kg capacity (3-phase required for 500 kg) Structural opening: 1505 × 1630 mm (through/single) or 1530 × 1630 mm (adjacent) |
1100 × 1580 mm |
500 kg capacity (3-phase required) Structural opening: 1505 × 1730 mm (through/single) or 1530 × 1730 mm (adjacent) |
Specialist Versions
The Aritco PublicLift Access is our standard model, for everyday commercial use, but two additional options are also available, each sharing the same core design. Whether installed inside a public building, outside an entrance, or in a mixed-use space handling both people and trolleys, there’s a model to meet your needs.
Outdoor
Built for external installations, this version includes C5-rated guide rails for corrosion resistance, a protective canopy, ventilation fans, and optional heater and roof systems. It provides dependable step-free access between outdoor and indoor levels.
Goods
Certified for light goods use, this version features a raised platform kerb and reinforced structure to handle trolleys and equipment safely. It can also carry passengers, offering a versatile option for mixed-use commercial spaces.
Options & Finishes
Lift Colours |
Standard Traffic White (RAL 9016). Optional finishes in any RAL K7 Classic colour (excluding pearl and fluorescent tones). |
Glazing |
Clear Glass
Tinted Glass |
Flooring Material |
Dark Grey, Vinyl
Aged Oak, Vinyl
Bolson Graphic
Bolson Sisal Plain Sand |
Handles/Handrails |
Closed-end rod handles in Traffic White or anodic Natura Grey. Integrated LED lighting as standard. |
Door Options |
GL full glass, EI60 fire-rated, or half-height gate |
Lighting |
Integrated LED ceiling downlights and illuminated handrail for visibility and safety. |
Sustainability and Efficiency
The 2.2 kW motor uses less energy than a standard household kettle. Low-energy LED lighting and display components further reduce running costs, while the efficient screw-and-nut drive system helps cut annual power use by up to 66% compared to conventional passenger lifts.
These standard features can deliver as much as 75% less CO₂ output over a year of typical use, making the Aritco PublicLift Access a truly sustainable choice for modern public and commercial buildings.
Technical Overview
Type |
Enclosed platform lift for public and commercial environments |
Compliance |
Machinery Directive 2006/42/EC; EN 81-41; Equality Act and Part M options available |
Drive System |
Patented screw and nut system |
Rated Speed |
Max 0.15 m/s |
Travel Height |
500–13,000 mm |
Floors Served |
2–6 |
Rated Load |
250 kg, 410 kg, or 500 kg |
Power Supply |
1-phase 230 V or 3-phase 400 V (3-phase required for 500 kg models) |
Motor Output |
2.2 kW |
Platform Controls |
Hold-to-run platform; one-touch landing call |
Doors per Floor |
Up to two |
Entry Sides |
One, two, or three |
Top Height |
2,240 mm standard; 1,100–1,600 mm with half-height gate (<3 m travel) |
Environment |
Internal or external (Outdoor variant available) |
Communication |
Alarm, digital telephone line, or GSM auto-dialler |
Door Locking |
Electrical |
Installation and Lifetime Support
Each lift arrives as a modular, self-contained unit, requiring only a shallow 50 mm pit or ramp for ground-level access. Most projects are complete within three to five days, without the need for head fixing, a machine room, or extensive building work.
After installation, our nationwide engineering network provides maintenance plans and responsive support to keep every lift operating safely and efficiently. All models include a 5-year product warranty, plus a 10-year warranty on the patented screw-and-nut drive system, assurance that performance will last well into the future.
With more than 30 years of experience and a reputation for reliability, Gartec combines expert service with enduring product quality.
Ready to Improve Access in Your Building?
Discuss your accessibility project with our expert team, from schools and offices to retail and public spaces. We’ll help you specify the right lift configuration for your site, budget, and compliance needs.
BOOK A FREE SURVEY
FAQs
Is the Aritco PublicLift Access Equality Act compliant? |
Yes. Larger platform sizes meet both Part M and Equality Act standards, providing inclusive access for wheelchair users and passengers with mobility aids in public or commercial buildings. |
Can the Aritco PublicLift Access be installed outdoors? |
Yes. The outdoor model includes corrosion-resistant C5-rated guides, canopy, ventilation, and optional heating. It’s ideal for external access between indoor and outdoor levels. |
What is the load capacity for goods use? |
The goods model lifts up to 500 kg and is certified for light goods and passenger use. Its reinforced platform and raised kerb protect the shaft during trolley or equipment loading. |
How long does installation take? |
Typically three to five days, depending on site conditions. The modular structure arrives with its own shaft enclosure, so only minimal building work is needed. |
Does the Aritco PublicLift Access need a pit or head fixing? |
Only a 50 mm pit or surface ramp is required for level access. No head fixing, machine room, or pump box is necessary. |
What finishes and door options are available? |
Standard Traffic White (RAL 9016) with optional RAL colours. Choose from clear or tinted glass panels, vinyl or rubber flooring, and single, double, half-height, or EI60 fire-rated doors. |
